Component Conversion Rules

Conversion rules define how one component type is converted into another component type.

auto conversion

One option is to automatically map based on matching directive keys. Take the following two components body and title with these html templates:

body having the template:

<p doc-editable="text"></p>

title having the template:

<h1 doc-editable="text"></h1>

With these samples, body and title can be automatically mapped based on the matching text content keys by defining a mapping with the type auto:

"body": {
    "title": "auto",
}

Any matching content keys of directives are copied to the new component. Non-matching directives are ignored and left empty.

simple conversion

Another option is to use explicit mapping. This can be used when the directive keys do not match, but you still want to create a mapping. Let’s look at the body and title components again, except now with the following html templates:

body having the template:

<p doc-editable="text"></p>

title having the template:

<h1 doc-editable="header-text"></h1>

"body": {
    "title": {
        "type": "simple",
        "map": {
            "header-text": "text"
        }
    }
}

Here the field with key text is mapped to the field header-text of the title component.

from-container conversion

This option can be used to turn a container type component into a regular component. It picks the first component of the container and discards the rest.

"slideshow": {
    "image": {
        "type": "from-container",
        "container": "slideshow"
    }
}

to-container conversion

This option can be used to automatically place a component into a container-like component.

"image": {
    "slideshow": {
        "type": "to-container",
        "container": "slideshow"
    }
}
